DM-500 Digital Conveyor

DM-500 DIGITAL METER 5 METER STROKE ROLLER CONVEYOR

FEATURES :

  • Right and left direction option depending on the machine to be integrated.
  • It allows you to make quality production by making perfect measurements with measurement precision.
  • For ease of use, it has the feature of retracting the stop, which allows the small size cut in lath cuts to come out of the mold.
  • Thanks to the 7” touch screen, it makes it easier to enter the size of the piece to be cut on the cutting machines.
  • Precise positioning of entered dimensions with Servo or Stepper motor option.
  • Ability to operate at high performance with reinforced power supplies.
  • It can be connected to any type of cutting or drilling machine.
  • It is suitable for prescription cutting. Thanks to the Counting Switch, it finds the position automatically in the next measure.
  • Language support.



TECHNICAL SPECIFICATIONS :

  • Voltage 220V 50hz
  • 0.1 mm Measurement accuracy.
  • Installation Dimension 550 cm
  • Movement Distance 500 cm
  • 7” Touch screen
  • One-button retracting feature that allows easy removal of the profile from the mold
  • Design providing maximum ease of use
  • It can be integrated into all machines.



MACHINE DIMENSIONS:

  • Height: Min. 50cm - Max. 100cm (Adjustable)
  • Width: 66cm
  • Length: 550cm
  • Weight: 110 kg.
  • Boxed Dimension: 60cm x 40cm x 480cm
  • Boxed Weight: 150 kg.



MOVEMENT DISTANCE:

  • Minimum profile length that can be processed is 5mm
  • Maximum processable profile length 5000mm
  • The distance from the connection point to the cutting machine to the cutting blade is added to the minimum length.
